Citadel BAT
Flexible battery-only energy storage platform.
Overview
The Citadel BAT Series is a modular battery energy storage cabinet designed for commercial and industrial applications. Combining high-performance Grade A LFP batteries, an intelligent Battery Management System (BMS), and advanced liquid cooling, it delivers safe, reliable, and scalable energy storage. Compatible with leading PCS and hybrid inverter manufacturers, the system supports flexible integration for peak shaving, backup power, renewable energy integration, microgrids, and utility-scale projects.
Technical Parameters
For more technical information, please refer to the technical brochure.
| Model | 208kWh-BAT- L | 156kWh-BAT-L | 104kWh-BAT-L |
|---|---|---|---|
Nominal energy | 208.96 kWh | 208.96 kWh | 104.48 kWh |
Nominal power | 50/100 kW | 50 kW | 50 kW |
Nominal voltage DC | 665.6 V | 499.2 V | 332.8 V |
Cell capacity | 314 Ah | 314 Ah | 314 Ah |
IP rating | IP55 | IP55 | IP55 |
Reference weight (t) | ≈ 2.05 t | ≈ 1.72 t | ≈ 1.39 t |
Cooling method | Liquid cooling | Liquid cooling | Liquid cooling |
